The Honda Activa 3g Head Light delivers superior nocturnal illumination, precision beam focus, and authentic showroom styling for your two-wheeler. Manufactured to exacting original equipment tolerances, this complete headlamp assembly replaces yellowed, fogged, or cracked factory lighting units, providing riders with maximum forward road visibility, razor-sharp beam cutoff, and rugged weather resistance under demanding nighttime riding conditions.
Workshop Guide & Diagnostic Standards for Honda Activa 3g Head Light
Upgrading your vehicle with this OEM-spec Bike Headlight restores optical beam throw, prevents blinding glare for oncoming traffic, and ensures dependable electrical reliability across city and highway routes.
1. Optical Polycarbonate Lens Clarity & Scratch-Resistant UV Hard-Coating
Fabricated from shatterproof, optical-grade virgin polycarbonate (PC), this front lens offers unmatched impact strength against airborne gravel and road debris. Treated with an exterior silicone-based UV hard-coating, the lens resists solar yellowing, micro-scratches from road grit, and thermal hazing caused by continuous halogen bulb operation, ensuring crystal-clear lumen transmission.
2. High-Vacuum Metallized Aluminum Parabolic Beam Reflector
The internal reflector dome is formed using automated high-vacuum aluminum vapor deposition protected by a transparent protective lacquer. Its computer-modeled parabolic contours gather light rays from the bulb filament and project an expansive horizontal low-beam spread that illuminates lane shoulders while projecting a piercing, high-intensity focal hotspot on high beam.
3. Vibration-Isolated Fairing Mounting & Pivoting Adjuster Screws
Engineered with factory-positioned mounting lugs and precision fairing cowl attachment tabs, this headlamp assembly installs seamlessly into your bike’s front cowl or triple-clamp fork bracket. High-grade spring-tensioned vertical and horizontal aiming adjuster screws allow mechanics to calibrate optical beam angle precisely according to rear suspension preload and rider weight.
4. IP67 Weatherproof Butyl Perimeter Sealing & Rear Dust Boot
To eliminate frustrating internal condensation and moisture pooling during monsoon riding or pressure washes, the polycarbonate lens is permanently bonded to the rear ABS housing using continuous hot-melt butyl rubber sealant. The bulb socket opening is shielded by a pliable, heat-resistant silicone dust boot that keeps water and dust out while allowing thermal expansion breathing.
5. Ceramic Bulb Socket Terminal Inspection & Voltage Drop Diagnosis
When installing your replacement headlight, workshop technicians should inspect the main wire harness coupler. Ensure the ground terminal wire (Green on Hero/Honda, Black/Yellow on Bajaj, Black/White on TVS/Suzuki) provides solid chassis continuity with zero voltage drop. We recommend utilizing ceramic-insulated 3-pin bulb sockets to eliminate socket melting under high-wattage bulb draw.
6. Vertical & Horizontal Beam Leveling Angle Adjustment
Proper beam alignment is critical for road safety. Position the motorcycle on level ground 5 meters away from a vertical wall with the rider seated. Adjust the rear pivoting aiming screw until the top cutoff line of the low-beam hotspot sits approximately 50 mm below horizontal headlamp center height, maximizing road illumination without blinding oncoming drivers.
7. Lens Surface Maintenance & Acrylic Polishing Protocols
To preserve the exterior optical clarity of your polycarbonate headlight, clean only with automotive car shampoo and soft microfiber towels. Never wipe dry lenses caked with road dust, as abrasive silica particles can scour the UV hard-coat. Quarterly applications of non-abrasive synthetic polymer sealant or spray ceramic wax maintain surface hydrophobicity and repel rain water during night rides.
Technical Specifications
| Specification Parameter | Engineering Standard |
|---|---|
| Lens Material Architecture | Optical-Grade Virgin Polycarbonate (PC) with UV Hard-Coat |
| Reflector Technology | High-Vacuum Aluminum Vapor Deposited Parabolic Dome |
| Housing Construction | High-Impact Heat-Resistant Automotive ABS Polymer |
| Perimeter Weatherproofing | Continuous Hot-Melt Butyl Gasket + Silicone Dust Boot (IP67) |
| Mounting Alignment | Direct OEM Factory Cowl Tabs & Bracket Interlock Holes |
| Application Compatibility | Direct Bolt-On Fitment for Honda Activa |
Frequently Asked Questions: Honda Activa 3g Head Light
Does the headlight assembly include the bulb?
This headlight assembly includes the complete lens, parabolic reflector, rear ABS housing, and rubber rear dust seal ready to accept your original or replacement HS1/H4/LED bulb.
Will this headlight lens turn yellow over time?
No. The lens is manufactured from optical-grade polycarbonate treated with an anti-UV hard-coating that resists solar oxidation, yellowing, and surface micro-scratches.
Can I adjust the beam angle after installation?
Yes. The assembly features factory-spec vertical aiming screws that allow you to calibrate high and low beam cutoff angles to match your riding preference.
Do you deliver bike headlights across India?
Yes. Free shipping across India.
Technical Specifications & Vehicle Fitment
- Part / OEM Code: e6aff260f1cb-1
- Compatible Two-Wheelers: Honda Activa 3G
- Brand / Specification: Autoss OEM Replacement
Fitment & Shipping FAQs
Q: Which bike models fit HONDA ACTIVA 3G HEAD LIGHT (e6aff260f1cb-1)?
This HONDA ACTIVA 3G HEAD LIGHT (Part/OEM Reference: e6aff260f1cb-1) is designed for compatible fitment with Honda Activa 3G. Please verify the mounting points and connector profile in the product photos before ordering.
Q: What is the catalog part number and brand for HONDA ACTIVA 3G HEAD LIGHT?
The catalog reference code / MPN is e6aff260f1cb-1 under Autoss OEM Replacement, supplied by Autoss.in (Elegant Innovations).
Q: What are the shipping timelines across India on Autoss.in?
All spare parts on Autoss.in are carefully packed and shipped pan-India through tracked courier partners including Delhivery, Xpressbees, and iCarry.
