BAJAJ Pulsar 150 6+2 PINs CDI UNIT DH111019

BAJAJ Pulsar 150 6+2 PINs CDI UNIT DH111019

The BAJAJ Pulsar 150 6+2 PINs CDI UNIT DH111019 is listed for the Pulsar 150 electrical application. Selection should start with the installed ignition controller, not solely with the bike model printed on packaging. To reduce incorrect orders, compare the installed module with the exact controller label and existing connectors; the name of the motorcycle by itself cannot prove compatibility.

Jump to: Identification | Checks | Installation | FAQs

Part identification and electronic compatibility

Use the printed reference DH111019 along with the listed model and version. The supplied description specifies a 6+2 PINs connector arrangement. Some items sold as CDI units are electronic ignition modules, TCI systems or fuel-injection controllers; these are not automatically interchangeable despite similar external housings.

• Vehicle: Pulsar 150; check the exact year, emission generation and starting mechanism.
• Part markings: DH111019; verify the complete number and suffix on your original component.
• Connectors: 6+2 PINs connector arrangement; count every plug group and the terminal positions on the actual fitted unit.
• Coupler appearance: Not verified; compare locking tabs and connector shape.
• Fitting: Compare mounting points, cable routing, connector locks and any version-specific wiring before installation.
• Claims: No unsupported OEM endorsement, water resistance, factory bench test or warranty promise is made.

Role of the ignition or engine-control module

For the Pulsar 150, the matching electronic controller participates in ignition operation according to the vehicle circuit. A CDI, TCI and fuel-injection control system can use different switching and sensor requirements. A replacement should preserve the original module application, rather than assume that more pins or a familiar housing will work with another version.

Keep connector pins clean, dry and undamaged when examining the removed component. The supply voltage, earth terminals, pickup signals and ignition coil must be considered together. If your motorcycle has been rewired or converted to aftermarket components, identify its current actual electrical configuration rather than relying only on the sales model name.

Electrical checks before replacement

Uneven ignition or misfiring at speed should prompt a workshop check of sensor inputs and related components. Have a qualified mechanic check power supply, earth continuity, ignition coil and relevant sensor or pickup signals using the correct servicing procedure. Where the application uses fuel injection, check the associated sensors and connector feeds instead of assuming a conventional capacitor-discharge controller.

When a Pulsar 150 has hard starting, intermittent running or no spark, test the motorcycle system first. Electronic modules are not a universal repair for dead batteries, damaged fuses, corroded couplers or disconnected wiring. Confirm that the installed part marking and every visible plug group correspond before ordering.

Connection and post-fitting checks

Switch off the Pulsar 150 safely before examining the electrical assembly. Follow the applicable servicing procedure and inspect the old harness for water damage, backed-out terminals or cut insulation. Do not force a different keyed plug, cut wires just to fit a replacement or swap terminals without verified wiring information.

After the matching module is installed, check mounting security, connector seating, normal starting and the relevant fault or charging indications for that model. If the original symptoms persist, have the rest of the ignition and engine-management circuits checked rather than replacing parts repeatedly.

Choosing your replacement from Autoss

Before ordering the BAJAJ Pulsar 150 6+2 PINs CDI UNIT DH111019, keep the removed module and its identifying label available for comparison. The BAJAJ Pulsar 150 6+2 PINs CDI UNIT DH111019 must also match the fitted electrical configuration. Parts that suit a different model year or harness can have different timing, circuit controls and connectors even if they appear similar. Browse the Autoss Bike CDI Unit category for other named versions only after technical matching.

Common questions about Pulsar 150 ignition modules

Q: Will the BAJAJ Pulsar 150 6+2 PINs CDI UNIT DH111019 fit every Pulsar 150?
A: Not necessarily. Confirm the full part marking, exact vehicle version and installed wiring connections.

Q: What does the DH111019 identification refer to?
A: It is a part-reference guide; compare the actual module label, all terminals and the wiring configuration.

Q: Will a new ignition-control unit cure a no-start fault?
A: Only when the original module has been correctly identified as faulty; the ignition coil, pickup, wiring and other systems may cause similar symptoms.

Q: Can a different Pulsar 150 year use the same unit?
A: Only if its ignition or engine-management circuit and module marking genuinely match; never assume across years or emissions versions.

Q: Is this product officially certified as OEM or waterproof?
A: No such unsupported manufacturing or weatherproofing claim is made in this listing.
